Key Features

Dual Panel Unlock

6 Digit Keypad

WiFi Capable

Fully Stainless Steel

5 Unlocking Methods

Suitable for Grille Door

Color

Silver, Black

Unlocking Methods

Fingerprint: Front & Back

Card: Front & Back

Password: Front & Back

App Remote Access: Front & Back

Key: Front & Back

Lock Mechanism

Auto Lock

Unlocking Mechanism: Semi Auto

Double Lock Mechanism: Handle Uplift

Standard Mortise Type: 2885

Mortise Material: 304SS

Connectivity

WiFi

WiFi mode: EZ

Zigbee (optional)

App Functions

Check-in Notification

Entry Logs and Records

Remote Unlocking

User Management

Temporary Password

Online Password

Lock Functions

Passage mode

Mute mode

Virtual Password

Language: English & Mandarin

Security

Low Battery Alarm

Hijack Alarm

Continuous Failure Alarm

Requirement

Door Thickness (mm): 25-100

Door and Frame Gap (mm): 3

Wooden Door to Grille Door Gap (mm): 100

Suitable Door: Grille Door

Capacity

Fingerprint Record: 100

Password Record: 100

Card Record: 100

Total Admin Capacity: 9

Total User Capacity: 300

Technical Specs

Body Material: Stainless Steel

Fingerprint Material: FPC Semiconductor

Lock Cylinder Grade: C

Waterproofing: Splashproof

Powered By: Tuya

Warranty: 2 Years

App: Smartlife

Battery USB Type: Micro

Battery Type: Lithium Rechargable

Battery Capacity (mAH)

Battery Life (Months): 6 – 9

Card Type: NFC

Working Temperature: -20 ~ 33

Working Voltage: 7.4v

Power: <=50µA

Working Current: 250mA

Emergency Power: Micro USB

Recognition Speed: <=1s

False Reject Rate (FRR): <=0.01%

Dimensions (cm)

Body Width (Front): 4.1

Body + Handle Width (Front): 14

Height (Front): 28.7

Max Depth (Front): 7.2

Min Depth (Front): 7.2

Body Width (Back): 4.1

Body + Handle Width (Back): 14

Height (Back): 28.7

Max Depth (Back): 7.2

Min Depth (Back): 7.2

Package List

Front Panel

Back Panel

2 Mechanical Keys

Lock Cylinder

WiFi Module

Accessories Pack

2 Access Cards

Mortise

Rechargeable Battery

Warranty Card

User Manual

Installation Guide
