Key Features
Face ID
Doorbell with Photo Capture
Digital Door Viewer with Camera
Photo Record
Single Panel Mortise Lock
Fully Auto
WiFi Capable
8 Unlocking Methods
Suitable for Wooden Door, Fire Door, Security Door
Color
Matte Black
Unlocking Methods
Face: Yes
Fingerprint: Yes
Card: Yes
Password: Yes
App Remote Access: Yes
Temporary Password: Yes
Key: Yes
Lock Mechanism
Auto Lock: Yes
Unlocking Mechanism: Fully Auto
Double Lock Mechanism: Fully Auto
Standard Mortise Type: 6068
Mortise Material: 304SS
Connectivity
WiFi: Yes
WiFi mode: AP
App Functions
Check-in Notification: Yes
Entry Logs and Records: Yes
Remote Unlocking: Yes
User Management: Yes
Temporary Password Type
Online Password: Yes
One Time Password: Yes
Lock Functions
Mute mode: Yes
Dual verify: Yes
Anti burglar alarm: Yes
Volume setting: Yes
Virtual Password: Yes
Language: English & Mandarin
Security
Lock Tampering Alarm: Yes
Low Battery Alarm: Yes
Hijack Alarm: Yes
Continuous Failure Alarm: Yes
Requirement
Door Thickness (mm): 40-120
Door and Frame Gap (mm): 3
Wooden Door to Grille Door Gap (mm): 100
Suitable Door: Wooden Door, Fire Door, Security Door
Capacity
Fingerprint Record: 100
Password Record: 100
Card Record: 100
Total Admin Capacity: 9
Total User Capacity: 300
Face ID Record: 50
Technical Specs
Lock Type: Single Panel Mortise Lock
Body Material: Aluminum Alloy
Fingerprint Material: FPC Semiconductor
LCD Screen: Yes
Lock Cylinder Grade: C
Waterproofing: Splashproof
Powered By: Tuya
Warranty: 2 Years
App: Smartlife
Battery USB Type: Micro USB
Battery Type: Lithium Rechargeable
Battery Capacity (mAH): 4200
Battery Life (Months): 6 – 9
Card Type: NFC
SD Card: Yes
Working Temperature: -20 ~ 33
Working Voltage: 7.4v
Power: <=50µA
Working Current: 250mA
Emergency Power: Micro USB
Recognition Speed: <=1s
False Reject Rate (FRR): <=0.01%
Dimensions (cm)
Body Width (Front): 7
Body + Handle Width (Front): 7
Height (Front): 43.4
Max Depth (Front): 6.5
Min Depth (Front): 5.5
Body Width (Back): 8
Body + Handle Width (Back): 8
Height (Back): 43.4
Max Depth (Back): 6.5
Min Depth (Back): 3.5
Package List
Front Panel: Yes
Back Panel: Yes
2 Mechanical Keys: Yes
Lock Cylinder: Yes
WiFi Module: Embedded
Accessories Pack: Yes
2 Access Cards: Yes
Mortise: Yes
Rechargeable Battery: Yes
USB Cable: Yes
Warranty Card: Yes
Installation Guide: Yes
