Key Features
Ultra Sleek & Modern Design
Fully Automatic
Long standby time
Lithium Rechargeable Battery
5 Unlocking Methods
Suitable for Wooden and Fire Door, Security Door

Color
Black, Rose Gold

Unlocking Methods
Fingerprint
Card
Password
App Remote Access
Key

Lock Mechanism
Auto Lock
Unlocking Mechanism: Fully Auto
Double Lock Mechanism: Fully Auto
Standard Mortise Type: 6068
Mortise Material: 304SS

Connectivity
WiFi
WiFi mode: EZ
Zigbee (optional)

App Functions
Check-in Notification
Entry Logs and Records
Remote Unlocking
User Management

Temporary Password
Online Password
One Time Password

Lock Functions
Mute mode
Dual verify
Anti burglar alarm
Volume setting
Virtual Password
Language: English & Mandarin

Security
Lock Tampering Alarm
Low Battery Alarm
Hijack Alarm
Continuous Failure Alarm

Requirement
Door Thickness (mm): 40-120
Door and Frame Gap (mm): 3
Wooden Door to Grille Door Gap (mm): 100
Suitable Door: Wooden Door, Fire Door, Security Door

Capacity
Fingerprint Record: 100
Password Record: 100
Card Record: 100
Total Admin Capacity: 9
Total User Capacity: 300

Technical Specs
Body Material: Aluminium Alloy
Fingerprint Material: FPC Semiconductor
Lock Cylinder Grade: C
Waterproofing: Splashproof
Powered By: Tuya
Warranty: 2 Years
App: Smartlife
Battery USB Type: Micro USB
Battery Type: Lithium Rechargable
Battery Capacity (mAH): 3200
Battery Life (Months): 6 – 9
Card Type: NFC
Working Temperature: -20 ~ 33
Working Voltage: 7.4v
Power: <=50µA
Working Current: 250mA
Emergency Power: Micro USB
Recognition Speed: <=1s
False Reject Rate (FRR): <=0.01%

Dimensions (cm)
Body Width (Front): 7.5
Body + Handle Width (Front): 7.5
Height (Front): 41
Max Depth (Front): 6
Min Depth (Front): 1.8
Body Width (Back): 7.6
Body + Handle Width (Back): 7.6
Height (Back): 41
Max Depth (Back): 6.5
Min Depth (Back): 2.7

Package List
Front Panel
Back Panel
2 Mechanical Keys
Lock Cylinder
WiFi Module
Accessories Pack
2 Access Cards
Mortise
Rechargeable Battery
USB Cable
Warranty Card
User Manual
Installation Guide
