Avant Guard Smart Grille Lock G11

Key Features
Dual Panel Unlock
Anti Prying Alarm
LCD screen
10 Digit with Doorbell
WiFi Capable
Ergonomic Design
5 Colors Selection
Long Standby Time
5 Unlocking Methods
Suitable for Grille Door

Color
Matte Black, Metallic Black, Silver White, Champagne Gold, Rose Gold

Unlocking Methods
Fingerprint: Front & Back
Card: Front & Back
Password: Front & Back
App Remote Access: Front & Back
Key: Front & Back

Lock Mechanism
Auto Lock
Unlocking Mechanism: Semi Auto
Double Lock Mechanism: Handle Uplift
Standard Mortise Type: 2885
Mortise Material: 304SS

Connectivity
WiFi
WiFi mode: EZ

App Functions
Check-in Notification
Entry Logs and Records
Remote Unlocking
User Management

Temporary Password
Online Password
One Time Password
Offline Password

Lock Functions
Passage mode
Mute mode
Dual verify
Anti burglar alarm
Volume setting
Virtual Password
Language: English & Mandarin

Security
Lock Tampering Alarm
Low Battery Alarm
Hijack Alarm
Continuous Failure Alarm

Requirement
Door Thickness (mm): 25-100
Door and Frame Gap (mm): 3
Wooden Door to Grille Door Gap (mm): 100
Suitable Door: Grille Door

Capacity
Fingerprint Record: 100
Password Record: 100
Card Record: 100
Total Admin Capacity: 9
Total User Capacity: 300

Technical Specs
Body Material: Zinc Alloy
Fingerprint Material: FPC Semiconductor
Lock Cylinder Grade: C
Waterproofing: Splashproof
Powered By: Tuya
Warranty: 2 Years
App: Smartlife
Battery USB Type: Micro
Battery Type: Lithium Rechargable
Battery Capacity (mAH)
Battery Life (Months): 6 – 9
Card Type: NFC
Working Temperature: -20 ~ 33
Working Voltage: 7.4v
Power: <=50µA
Working Current: 250mA
Emergency Power: Type C
Recognition Speed: <=1s
False Reject Rate (FRR): <=0.01%

Dimensions (cm)
Body Width (Front): 4.3
Body + Handle Width (Front): 13.5
Height (Front): 33
Max Depth (Front): 6.8
Min Depth (Front): 2.7
Body Width (Back): 4.3
Body + Handle Width (Back): 13.5
Height (Back): 33
Max Depth (Back): 6.8
Min Depth (Back): 2.7

Package List
Front Panel
Back Panel
2 Mechanical Keys
Lock Cylinder
WiFi Module
Accessories Pack
2 Access Cards
Mortise
Rechargeable Battery
USB Cable
Warranty Card
User Manual
Installation Guide
